Whirlpool W10854222 Electronic Control Board (Console) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10854222 replaces AP6003891, 4454430, PS11731270, W10746419, W10757526, W10833928.

Description

This electronic control board replaces the console control module that manages oven functions and display. It restores responsive touch/pad commands and proper cycle control so the appliance runs settings and timers correctly. What it does:

• Receives input from the control panel and sends signals to bake, broil, timers and display components
• Regulates oven functions and user-interface feedback for accurate operation
• Commonly replaced for unresponsive controls, blank or erratic display, or incorrect cycle behavior
• Works with the appliance's main power and relays to initiate heating and timing sequences

What's included:

• One electronic control board

Install notes:

• Disconnect power at the breaker or unplug the appliance before starting work
• Handle the board by its edges and avoid static discharge; use ESD protection if available
• Follow the appliance service manual for access, mounting, and connector reassembly
