Whirlpool W10860347 Electronic Control Board (Main Console) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10860347 replaces AP6027270, 4459412, PS11759599.

Description

This electronic control board manages the appliance's user interface and cycle operations, restoring responsive controls and proper cycle sequencing. It replaces a failed or unresponsive main console board to bring back normal control functionality. What it does:

• Interprets user inputs from the console and sends signals to start and control cycles
• Manages timing, cycle selection, and communication with other modules
• Common symptoms it can fix: unresponsive buttons, no power to controls, incorrect or stuck cycles, and error code displays
• Works as the primary logic board that coordinates operation of motors, valves, and sensors

What's included:

• One electronic control board (main console)

Install notes:

• Disconnect power to the appliance before servicing to prevent shock
• Handle the board by the edges and avoid static discharge; use an anti-static wrist strap if available
• Verify connector orientation and secure all wire harnesses before reassembly
