Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number W10860437 replaces AP6026285, W10721255, W10726395, 4451588, PS11737993.
Description
This is the appliance's main electronic control board. It interprets user and sensor inputs and switches onboard relays to run the proper functions and timing, restoring normal operation when the original board fails.
- Processes keypad and sensor signals to control the appliance's functions
- Sequences operations and timing by energizing relays to connected components
- Typical symptoms: unresponsive controls, won't start, erratic cycling, blank or garbled display, recurring error codes
What's included: 1 electronic control board Install notes:
- Disconnect power to the appliance before servicing
- Use ESD protection and handle the board by the edges
- Photograph/label wiring; move each harness and any jumpers/settings to the same locations on the new board
- After installation, restore power and run model-specific diagnostics or calibration per the service manual
