Whirlpool W10866117 Electronic Control Board (Cntrl-Elec, Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10866117 replaces AP6027290, W10813312, 4459702, PS11759621, W10403607, W10403610, W10509837, W10567083, W10598482, W10641979, W10643057, W10745398, W10796282, W10842316.

Description

This electronic control board is the appliance's central controller. It interprets sensor and keypad inputs and directs power to components, helping restore stable, predictable operation when the original board becomes unresponsive, erratic, or fails.

• Serves as the main logic board, processing inputs and controlling outputs to run designed functions
• Distributes power through onboard relays to components such as motors, valves, heaters, fans, or lights
• Manages timing and operating modes; faults may cause no response, functions not starting/advancing, intermittent operation, or recurring control-related error codes
• Works with model-specific diagnostics; the tech sheet if control-related faults persist

What's included: 1 electronic control board Install notes:

• Disconnect power at the breaker or unplug the appliance before servicing
• Use ESD precautions; handle the board by its edges only
• Photograph wiring and transfer connectors one at a time to the same locations; do not force terminals
• After installation, follow your model's tech sheet for any required initialization or diagnostic checks
