Whirlpool W10906421 Electronic Control Board (Oven/Range) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10906421 replaces AP6036141, 4460915, PS11769627, W10834729, W10873297.

Description

Electronic control board for oven and range consoles. Replaces the main console control to restore oven functions, display, and user interface so the range responds correctly to commands and cycle selections. What it does:

• Acts as the main control that manages bake, broil, timers and oven temperature signals.
• Powers and communicates with the front display and touch/keypad so settings show and respond.
• Common symptoms: blank or flashing display, unresponsive touchpad/buttons, incorrect cycles, or oven that won't start or heat as expected.
• Works with the range's wiring harness and associated sensors/relays to coordinate cooking functions.

What's included: One electronic control board. Install notes:

• Disconnect power at the breaker or unplug the appliance before starting any repair.
• Handle the board carefully; disconnect the ribbon and wire harness connectors by their housings to avoid damaging pins.
• Observe anti-static precautions and avoid touching circuit traces or components.
• Verify correct connector orientation and secure mounting; restore power and test all functions after installation.
