Whirlpool W10915648 Electronic Control Board (Cntrl-Elec) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10915648 replaces AP6038159, W10510103, W10811595, 4461221, PS11769949, W10577815.

Description

This electronic control board is the appliance's main control module. It interprets inputs, manages timing, and sends power to the proper components so cycles run correctly. Replacing a failed board can restore normal operation and responsive controls. What it does

• Processes signals from sensors and the user interface to execute programmed cycles
• Switches internal relays to power motors, valves, heaters, fans, or other loads as required
• Regulates timing, sequencing, and safety interlocks for reliable operation
• Common symptoms of a failed board: unresponsive controls, won't start, intermittent operation, cycle stalls, or error codes/alarms

What's included

• 1 electronic control board

Install notes

• Disconnect power at the breaker or unplug the appliance before servicing
• Use ESD protection; handle the PCB by its edges and avoid static-sensitive components
• Photograph/label connectors and transfer wiring one at a time to the new board
• Follow model-specific service instructions; some models may require entering service mode for configuration or calibration after installation
