Whirlpool W11035841 Refrigerator Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11035841 replaces AP6039982, 4461760, PS11773175, W10759661, W10887255, WPW10759661.

Description

This genuine OEM part is a control board for refrigerators. The control board assembly is the main circuit board that controls the refrigerator's essential functions such as adjusting and maintaining temperature. Over time, a refrigerator's control board can become inoperable due to excessive use. If the refrigerator is no longer cooling and failing to maintain its desired temperature, the control board will need to be replaced.To replace the control board, start by unplugging the refrigerator. After that, open the refrigerator door and remove the side panel to gain access to the old control board. Once accessed, detach the wire harness and any individual wires attached to the control board assembly. Unfasten the mounting screws holding the assembly in place, and pull the control board out. Set it to the side, and proceed to install the new board. Reattach the wires in their correct terminals, and secure the side panel of the refrigerator.This genuine replacement part is sold individually and is sourced directly from the manufacturer. It is compatible with Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Sears, and Kenmore brand refrigerators.
