Whirlpool W11101581 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11101581 replaces AP6238059, W10624968.

Description

This electronic control board operates the appliance's user interface and timed functions so cycles start, run and display correctly. Replacing a faulty board restores control logic and cycle sequencing. What it does:

• Controls cycle selection, timing and display signals for the appliance
• Processes user commands from the console and sends power signals to components
• Common symptom: appliance won't start or respond to controls
• Common symptom: display is blank, shows error codes, or cycles don't advance
• Common symptom: intermittent operation or unpredictable cycle behavior

What's included: One electronic control board Install notes:

• Disconnect power (unplug or shut off circuit/breaker) before servicing
• Handle the board by its edges and avoid static discharge; use an anti-static wrist strap if available
• Verify wiring harness connections and any fuses or thermal cutouts before and after installation
