Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number W11103646 replaces AP6238096, 4534528, PS12074693, W11084385.
Description
This electronic control board manages the appliance's timed cycles, sensor inputs and user commands so the unit operates as designed. Replacing a faulty control restores normal cycle control and electronic functions. What it does:
- Receives commands from the user interface and runs timed cycles and programs
- Monitors sensor signals and switches power to motors, heaters or valves as needed
- Helps regulate cycle timing, display feedback and error reporting
- Faulty boards can cause no power/no display, unresponsive controls, or cycles that won't start or advance
What's included: One electronic control board. Install notes:
- Disconnect power to the appliance before starting any work to avoid shock or injury
- Handle the board by its edges and avoid touching components; static discharge can damage electronics
- Verify harness connections are fully seated and routed clear of moving parts before testing
- After installation, restore power and run a short test cycle to confirm normal operation
