Whirlpool W11113731 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11113731 replaces AP6248482, 4842686, PS12114187, W10921620.

Description

This electronic control board replaces the appliance's main control board to restore control panel functions and cycle management. It provides the logic and user-interface connections the appliance needs to operate correctly. What it does:

• Receives and processes user inputs from the control panel so settings and cycles run as selected
• Controls timing, relay outputs and cycle sequencing for proper operation
• Can cause unresponsive buttons, no display, or incorrect cycles when faulty
• Stops intermittent starts or unexpected shutdowns tied to control board failure

What's included: One electronic control board as shown. Install notes:

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Handle the board by its edges and avoid touching components; use ESD protection when available
• Remove necessary panels and disconnect wiring harnesses carefully; note connector locations before removal
