Whirlpool W11116591 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11116591 replaces AP6261033, 4547435, PS12114297, W10803587, W10841369, W10865066, W10915786, W10916482.

Description

This electronic control board is the appliance's main logic module that runs user commands and manages cycle operations, restoring responsive controls and proper program sequencing when the original board fails. What it does

• Processes user inputs and sends signals to motors, valves, heaters, and other components
• Controls cycle timing, display updates, and start/stop functions
• Common symptoms indicating a failed board: unresponsive touchpad/buttons, no display or erratic display, unit won't start or complete cycles
• Replacing this board can stop intermittent or unexplained operational failures tied to control electronics

What's included One electronic control board Install notes

• Disconnect all power before starting — this part carries live voltage when energized
• Handle the board by its edges and avoid touching component pins or contacts
• Match part number and connector layout exactly; reconnect all wiring harnesses and secure mounting screws
