Whirlpool W11116594 Electronic Control Board (Console) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11116594 replaces AP6261036, 4591603, PS12114300, W10863406, W10885320, W10910381, W10916229, W10916485, W11048591, W11082577.

Description

This electronic control board is the console control that manages oven functions, timers and user inputs so the appliance responds correctly. Replacing a faulty board restores proper control, display feedback and cycle operation. What it does

• Receives input from the console and runs oven/range cycles, timers and display functions.
• Regulates the appliance control logic that starts and stops heating and timing functions.
• Common symptoms of a failing board: blank or flashing display, unresponsive buttons, incorrect cycles, or persistent error codes.
• Works as the main interface between user commands and appliance operations.

What's included One electronic control board. Install notes

• Disconnect all power at the breaker before servicing to avoid shock risk.
• Remove the console or control panel; keep track of screws and connectors.
• Take photos of wiring before disconnecting; transfer connectors exactly to the replacement.
• Handle the board carefully to avoid static discharge or damage.
