Whirlpool W11122533 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11122533 replaces AP6261060, 4546323, PS12114358, W10834011, W10887923, W11048737.

Description

This electronic control board is the brain of the appliance, directing cycles and powering key components. Replacing a failed board helps restore proper operation, reliable starts, and accurate cycle sequencing. What it does:

• Coordinates inputs from sensors and the user interface to control programmed functions
• Sends power to motors, pumps, fans, valves, and heaters as needed
• Manages cycle timing and safety checks
• Common symptoms include: won't power on or start, won't advance/complete, stops mid-cycle, erratic operation, or error codes

What's included:

• 1 electronic control board

Install notes:

• Disconnect power at the breaker or unplug before servicing
• Use ESD protection; handle the board by the edges to avoid static damage
• Move connectors one at a time from the old board to the new board; each is fully seated
• Secure the board in its housing/bracket, reassemble, and run a test/diagnostic cycle if available

Also known as: main control, control module, CNTRL-ELEC, control PCB
