Whirlpool W11124710 Electronic Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11124710 replaces AP6262431, W10914909, 4547172, PS12347385, W10868064, W10897771, W10902804, W10916445.

Description

This electronic control board is the appliance's central controller. It interprets inputs and switches outputs to run the unit's functions reliably, helping restore normal operation when controls are dead, erratic, or the machine won't run.

• Receives signals from the user interface and sensors, then processes logic to manage operation
• Activates relays to power the appropriate components as designed
• Coordinates timing, safety interlocks, and diagnostics
• Failure signs: unresponsive control panel, won't start, random beeps/lights, or error codes
• Visual clues can include burn marks or a damaged component on the board

What's included: 1 electronic control board Install notes:

• Disconnect power at the breaker or unplug before servicing
• Use anti-static precautions; handle the board by its edges
• Document wire/connector locations; transfer any brackets or jumpers from the original board
• Ensure all connectors are fully seated, restore power, and run a functional test per the service sheet
