Whirlpool W11133021 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11133021 replaces AP6278092, W11098430.

Description

This electronic control board serves as the appliance's main control, coordinating functions and powering key components. Replacing a failed board can restore reliable operation, accurate timing, and responsive controls.

• Directs operations based on user selections and sensor inputs to run each cycle
• Distributes power to motors, pumps, valves, and heaters as required
• Interfaces with the door/lid switch and user interface to start and advance cycles
• Common failure symptoms: won't start or no response from controls; stuck mid-cycle or won't advance; intermittent power; error codes or beeping

What's included: 1 electronic control board Install notes:

• Disconnect electrical power before servicing; follow all safety procedures
• Use ESD protection and handle the board by its edges
• Transfer wiring/connectors one at a time; reuse existing bracket/mounting hardware as applicable
• After installation, restore power and run the unit's diagnostic/service routine to verify operation and clear stored faults
