Whirlpool W11170645 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11170645 replaces AP6285269, W11101495.

Description

• Coordinates cycle logic and timing for proper operation
• Controls power to loads such as motors, valves, fans, and heaters
• Monitors inputs from switches and sensors; stores/triggers error codes
• Interfaces with the user controls; faults can cause unresponsive or flickering displays
• Common symptoms include no start, won't run or advance, intermittent shutdowns, or random error alerts

• Disconnect power at the breaker or fuse before servicing
• Use ESD precautions; handle the board by the edges to avoid static damage
• Photograph and label connections; transfer any jumpers and mounting hardware from the original board
• After installation, restore power and run the unit's service/diagnostic procedure or programming steps (see the tech sheet inside the appliance)
