Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
See all items in Washer Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number W11201274 replaces AP6327316, 4591556, PS12349094, W10750562, W10864047, W10885568, W10888194, W10899762, W10902312, W10908745, W10920559, W11092672, W11195081.
Description
The Control Board is an OEM part for Whirlpool washing machines. It is an electronic module responsible for operating and monitoring all functions of the washer. The control board receives input signals, interprets programs, and executes commands to complete cycles.
Causes of control board failure can be wear and tear over time, exposure to water damage, or electrical surge issues. Replacing the control board with this OEM Whirlpool part will restore full functionality to your washer.
Symptoms of a bad control board include:
- The washer fails to start or run cycles
- Strange cycling issues or failure to advance through cycles
- Error codes displaying
- Unresponsive buttons or displays
- Inability to select options
This genuine OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.
