Whirlpool W11230134 Electronic Control Board (Console) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11230134 replaces AP6331276, W11171160.

Description

This electronic control board manages the appliance's console functions and signals, letting user selections run the correct cycles. Replacing a failed control board can resolve unresponsive controls and erratic cycle behavior. What it does

• Receives inputs from the console (buttons/touchpad) and sends control signals to the appliance's systems.
• Regulates cycle timing and mode selection for proper operation.
• Common symptoms it can address: blank or flickering display, unresponsive buttons or touchpad, appliance won't start or stops mid-cycle, or persistent error codes.
• Restores normal control communication when the original board is faulty or intermittent.

What's included

• One electronic control board.

Install notes

• Disconnect power (unplug or switch off breaker) before starting any service.
• Handle the board by its edges; avoid touching components and contacts to prevent damage.
• Use proper anti-static precautions and ensure all wire harness connectors are fully seated and routed as originally installed.
