Whirlpool W11282990 Electronic Control Board (Console) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11282990 replaces AP6800007, W10727057, W11281880, WPW10727057.

Description

• Controls oven/range functions such as bake, broil, timers and display output.
• Processes touchpad/knob commands and sends signals to heating elements and relays.
• Addresses symptoms like a blank or flashing display, unresponsive controls, or failure to start heating cycles.
• Works with the appliance's user interface and safety interlocks to coordinate operation.

• One electronic control board.

• Disconnect power at the breaker or unplug the appliance before starting any work.
• Handle the board by its edges and avoid static discharge; use proper ESD precautions.
• Verify wiring matches the new board and document connections before removal.
• Test the appliance after reconnecting power and before full reassembly.
