Whirlpool W11387533 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11387533 replaces AP6973076, W11176897.

Description

This electronic control board replaces a failed range/oven main control to restore timed functions, displays, and cycle control. It mounts behind the console and communicates with the keypad and heating elements for normal operation. What it does:

• Receives input from the front-panel keypad or touchpad and controls oven/range functions
• Manages bake, broil, timers, and display indicators so cycles start and stop correctly
• Can resolve symptoms like unresponsive controls, incorrect/displayed error codes, or cycles that won't start
• Routes power signals to relays that activate heating elements and other components

What's included:

• One electronic control board

Install notes:

• Disconnect power at the breaker or unplug the appliance before starting any work
• Handle the board carefully to avoid static damage; avoid touching circuit traces and connectors
• Note connector locations and wire positions for correct reassembly; take photos if helpful
• After installation, restore power and verify functions before fully reassembling the console
