Whirlpool W11484625 Electronic Control Board (Console Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11484625 replaces AP6995505, W11230098, W11486733.

Description

This electronic control board manages the oven's user interface and cycle operations, restoring reliable control and consistent oven functions. It replaces a failed console board to help the oven accept settings and run selected bake/broil cycles. What it does:

• Controls user inputs, display, and command signals for oven functions
• Manages bake/broil timing and cycle selections so settings start and stop correctly
• Can resolve symptoms like unresponsive or blank control display, error codes, or intermittent cycle starts
• Works with existing wiring harness and user interface; does not include door, keypad, or sensors

What's included:

• One electronic control board

Install notes:

• Disconnect power at the breaker before accessing or replacing the control board
• Handle the board by edges and avoid touching components or connector pins to prevent static damage
• Verify wiring harness connections and any related thermal sensors or switches during replacement
• If error codes persist after replacement, test related components (thermostat, sensors, door switches) per OEM diagnostics
