Whirlpool W11550649 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11550649 replaces AP7034330.

Description

This electronic control board manages the appliance's core functions and user controls, restoring responsive buttons and proper cycle control when the original board fails. Fits as the main control module for affected units. What it does:

• Receives commands from the user interface and runs cycle logic for timing, temperatures, and heater/motor relays.
• Manages the display and indicator lights; a faulty board can cause blank or erratic displays.
• Can cause unresponsive controls, incorrect cycle behavior, or failure to start when damaged.
• Works with sensors and switches to regulate cycle progress and safety features.

What's included: One electronic control board. Install notes:

• Disconnect power to the appliance before starting any repair to avoid shock or injury.
• Document connector locations (take a photo) before removal to ensure correct reassembly.
• Handle the board by its edges and avoid touching components; protect against static discharge.
• Reconnect all wiring securely and restore power to verify operation.
