Whirlpool W11550652 Electronic Control Board (Console) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11550652 replaces AP7034331, W11482415, W11550536.

Description

This electronic control board replaces the appliance's main console brain to restore cycle selection, timing and user interface responses. It's a direct-fit board that lets the appliance accept commands and run programmed cycles. What it does:

• Controls cycle selection, run timing and user-interface functions
• Powers and communicates with display, buttons and other control components
• Commonly replaces boards when the appliance is unresponsive, shows erratic behavior, displays error codes, or cycles won't start
• Restores normal electronic control when the original board has failed

What's included:

• One electronic control board

Install notes:

• Disconnect power before beginning service to avoid shock or damage
• Remove the control console/panel to access the board
• Handle the board carefully and avoid touching contacts; use ESD precautions if possible
• Reconnect all wire harnesses securely and test the appliance with power restored
