Whirlpool W11680389 Electronic Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11680389 replaces AP7216863.

Description

This electronic control board is the appliance's central controller. It interprets user inputs and sensor feedback, then switches power to the correct components at the right time so everyday functions operate predictably and safely.

• Coordinates appliance operations by managing timing, logic, and sequencing
• Interprets signals from the user interface and sensors to execute commands
• Switches power to loads via onboard relays
• Monitors for faults and stores or displays error codes when issues are detected
• Common failure signs: unresponsive controls/display, won't start or run, intermittent shutdowns, functions not activating, or recurring error codes after other causes are ruled out

What's included: 1 electronic control board Install notes:

• Disconnect power at the breaker before servicing; verify no voltage is present
• Use ESD protection; handle the board by the edges and avoid flexing it
• Photograph connectors and move wires one at a time to the matching terminals
• Transfer any model-specific jumpers, brackets, or covers from the original as directed; run the unit's diagnostic/calibration routine if required by the tech sheet
