Whirlpool WPW10503833 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10503833 replaces AP6022410, 4447819, PS11755743, W10503833.

Description

This electronic control board is the appliance's main control, coordinating sensors, switches, and the user interface so cycles run correctly. Replacing a failed board restores operation when the unit is unresponsive, stuck in a cycle, or behaving erratically.

• Coordinates the timing and sequence of operations based on selected settings
• Sends power to motors, valves, heaters, fans, and lights as needed
• Monitors inputs from sensors and switches to adjust performance and protect components
• Common symptoms: won't start or power on; unresponsive controls; cycle won't advance; intermittent operation
• Stores or displays/blinks error codes when faults are detected

What's included: 1 electronic control board Install notes:

• Disconnect power at the breaker or unplug the appliance before servicing
• Use ESD/anti-static precautions; handle the board by its edges
• Photograph wiring and move connectors one at a time to the new board
• Refer to the unit's tech sheet for any required configuration or post-install service test
