Whirlpool WPW10542000 Electronic Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10542000 replaces AP6022777, W10542000, 4448193, PS11756114.

Description

This electronic control board is the "brain" of the appliance, interpreting user inputs and directing power to key components. Replacing a failed board restores responsive controls, correct timing, and dependable operation.

• Coordinates appliance operations and cycle timing based on user selections and sensor feedback
• Switches relays to run motors, valves, heaters, fans, and lights as designed
• Interfaces with the console/display to show status and error codes
• Common failure signs: blank or unresponsive controls, won't start or advance, erratic beeps/lights, recurring control-related error codes

What's included: 1 electronic control board Install notes:

• Disconnect power (unplug or switch off the circuit breaker) before servicing
• Use ESD precautions; handle the board by its edges and avoid touching components
• Photograph wire connections and transfer connectors one at a time; ensure they are fully seated
• Inspect harnesses/terminals for heat damage; run any required diagnostics or control calibration after installation
