Whirlpool WPW10654006 Electronic Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10654006 replaces AP6023624, W10654006, 4449051, PS11756969.

Description

This electronic control board is the appliance's central control module. It coordinates power and timing so selected cycles run correctly. Replacing a failed board can restore responsive controls and consistent, reliable operation.

• Directs power to motors, valves, heaters, and fans through onboard relays
• Interprets inputs from sensors and the user interface to execute the chosen cycle
• Common failure symptoms: unresponsive controls or blank display, won't start or run, cycles that won't advance or stop unexpectedly, intermittent operation, repeated clicking or control-related error codes
• Restores intended timing and component sequencing when the original board is shorted or damaged

What's included: 1 electronic control board Install notes:

• Disconnect power at the breaker or unplug the appliance before servicing
• Use ESD precautions; handle the board by its edges to avoid static damage
• Photograph/label all connectors; transfer any jumpers or selector plugs from the old board to the new one
• Ensure all connectors are fully seated and the board is secured before restoring power and testing
