Whirlpool W10798004 Control Box (Electronic Control Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10798004 replaces AP5988351.

Description

This electronic control assembly regulates the appliance's operation, simplifying cycle selection and timed functions so the unit runs as designed. It restores control communication between user inputs and internal components. What it does

• Receives user commands and runs the selected cycles or modes.
• Controls timing, relay outputs and signals to motors, pumps, valves or heaters.
• Manages the control panel display and indicator lights.
• Common symptom indicators: unresponsive controls, no power to cycles, error codes, or cycles that won't start/advance.

What's included One electronic control assembly. Install notes

• Disconnect power before service to avoid electrical shock.
• Handle the board by edges and avoid static discharge; use ESD protection if available.
• Verify connectors are fully seated and wiring harness orientation before reassembly.
