Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number W11496882 replaces AP7033550, W11130833, W11199717, W11221330, W11282568, W11396165.
Description
This control box is the appliance's electronic control module that manages user inputs and system functions, restoring reliable cycle selection and timed operations when the original control becomes faulty or unresponsive. What it does
- Receives and processes commands from the control panel and keypad.
- Controls timing, cycles and power to motors, valves, heaters, or other subsystem components.
- Helps resolve symptoms such as unresponsive controls, incorrect cycle operation, or intermittent starting.
- Works as the main logic board that communicates status and error conditions to the display.
What's included One control box assembly as shown. Install notes
- Disconnect power before starting any repair to avoid shock or damage.
- Access typically requires removing exterior panels or console; handle connectors gently.
- Protect the board from static — avoid touching circuitry and use ESD precautions if possible.
