Whirlpool WPW10226156 Electronic Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10226156 replaces AP6017385, W10226156, 1872745, PS11750683.

Description

This electronic control board is the brain of the appliance, interpreting inputs and switching power to key components. Replacing a failed board can restore proper operation when the unit won't start, is unresponsive, throws recurring error codes, or behaves erratically.

• Coordinates cycle timing and settings based on user selections and sensor feedback
• Controls relays to motors, heaters, valves, fans, lights, and other loads
• Monitors inputs and stores/communicates diagnostic error codes
• Symptoms of a failing board include no power to controls, won't start, intermittent or erratic operation, or repeated error codes

What's included: One electronic control board. Install notes:

• Disconnect power (and water/gas supply if applicable) before servicing
• Use ESD precautions; handle the board by the edges and avoid touching connectors or components
• Photograph/label all wiring; transfer any jumpers, DIP-switch positions, or ID labels from the original board if present
• After installation, ensure all connectors are fully seated and follow the unit's tech sheet for any required setup, programming, or service-mode steps
