Whirlpool WP2303091 Electronic Control Board (Phoenix Zone) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP2303091 replaces AP6007121, 2303091, 1174711, PS11740228.

Description

This electronic control board replaces the cooktop/oven Phoenix Zone control module to restore user interface and control of heating functions. It manages touch/display inputs and coordinates power to the cooking zones for normal operation. What it does:

• Receives touchpad or control panel commands and sends signals to the cooktop/oven systems
• Regulates heating outputs for Phoenix Zone circuits and communicates with sensors
• Can resolve symptoms like a blank or flickering display, unresponsive touch controls, or zone heating failures
• Works as the main logic board that interprets user inputs and runs control routines

What's included: One electronic control board Install notes:

• Disconnect all power to the appliance before starting any work
• Handle the board by the edges and avoid static discharge; use proper ESD precautions
• Verify connections and mounting; hardware and connectors must match exactly
• Some repairs may require programming, calibration, or service—refer to the OEM service manual
