Whirlpool W11173616 Power Cord (Cord Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11173616 replaces AP6284671, 98014532, W10640762, 4547032, 6610433, 98014531, PS12348235.

Description

This replacement power cord restores the appliance's main AC connection so it can receive power safely. Use this cord when the original cable is frayed, cut, melted, or otherwise damaged to prevent intermittent power or electrical hazards. What it does:

• Replaces the appliance's factory power cable to restore reliable electrical connection.
• Transmits mains power from the outlet to the appliance's internal wiring and controls.
• Addresses symptoms such as no power, intermittent power loss, visible cord damage, or burn/melt marks at the cord or plug.
• Helps prevent electrical arcing or shorting caused by damaged insulation or exposed conductors.

What's included: One replacement power cord assembly. Install notes:

• Disconnect the appliance from power at the breaker or unplug before starting any work.
• Verify the cord matches the appliance's connector and routing; do not modify cord ends or splices.
• Secure all strain reliefs and terminal connections per the appliance's service instructions.
