Whirlpool WPW10508311 Pan Cover Assembly (Refrigerator Crisper) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10508311 replaces AP6022452, 4447861, PS11755785, W10508311.

Description

This pan cover assembly is the shelf frame that sits above the refrigerator's lower drawers. It restores a sturdy surface and smooth drawer operation when the original cover is cracked, warped, or missing.

• Forms the top of the crisper/deli area and supports the glass shelf insert
• Provides integrated tracks so drawers slide in and out properly
• Helps keep food items level and prevents the shelf from sagging
• Common symptoms: cracked frame, broken tabs, glass won't sit flat, drawers bind or won't close fully

What's included: One pan cover assembly. Install notes:

• Disconnect power and clear the affected shelf area
• Remove the drawers and the glass insert, if present
• Lift out the damaged cover; transfer any removable trims or seals if needed
• Seat the new cover level, reinstall the glass and drawers, then restore power
