Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number WPW10195344 replaces AP6016757, W10195344, 4442102, PS11750050.
Description
This electronic control board is the dishwasher's main "brain," coordinating the fill, wash, drain, and dry sequences. Replacing a failed board can restore normal operation when the dishwasher is unresponsive, won't start cycles, or behaves erratically.
- Directs power and timing to valves, pumps, and heater for each cycle step
- Monitors inputs from sensors and the door latch to advance or pause the cycle
- Communicates with the user interface for button inputs and status lights
- Typical failure symptoms: no power to controls or won't start; stops mid-cycle or won't advance; blinking lights or error codes; intermittent operation
What's included: One electronic control board Install notes:
- Disconnect power at the breaker before servicing; verify no power at the dishwasher
- Access location varies by model; commonly behind the lower toe panel in a protective control housing
- Handle the board by the edges and use ESD protection; move wire connectors one at a time to the new board and secure the housing
- After installation, run the built-in diagnostics per the tech sheet; some models may require control configuration
