Whirlpool W10793634 Detergent And Rinse Aid Dispenser Assembly (Dishwasher) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Dispenser.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10793634 replaces AP5982375, 4283004, PS11703400, W10680194, W10777969.

Description

This dishwasher dispenser stores detergent and rinse aid and releases them at the correct points in the cycle to support consistent cleaning results. Replace a broken, stuck, or leaking dispenser to restore reliable detergent delivery.

• Holds detergent and rinse aid and dispenses them automatically during the wash and rinse portions of the cycle
• Door/actuator mechanism controls the timed release of detergent
• Seals help prevent leaks around the dispenser opening
• Typical failure symptoms: detergent cup won't latch or open, detergent left in the cup, rinse aid not dispensing, or leaks from the dispenser area

What's included: One dispenser assembly Install notes:

• Disconnect power and turn off water supply before servicing
• Remove the inner door panel to access the dispenser; disconnect the wire connector
• Release mounting screws/clips, clean the door cutout, and seat the new dispenser evenly
• Tighten screws in a cross pattern to compress the gasket uniformly; run a test cycle to check for leaks and proper operation
