Whirlpool WPW10084086 Door Balance Mount (Dishwasher) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10084086 replaces AP6014941, W10084086, 4440254, PS11748211, W10084084, W10084085.

Description

The door balance mount is the side-frame bracket that supports the dishwasher's door counterbalance system. When worn or broken, it can let the door drop, slam, bind, or feel heavy. Replacing it restores smooth, controlled door movement. What it does

• Anchors the door springs and balance link/cable to counterbalance the door's weight
• Helps the door open and close smoothly without dropping or slamming
• Guides the balance link for consistent, quiet movement
• Common symptoms: door feels heavy or uneven, falls open, won't stay put, or makes grinding/squeaking noises; visible damage to the bracket or rollers

What's included

• One door balance mount (bracket)

Install notes

• Disconnect power and shut off water before servicing
• Pull the dishwasher out slightly to access the side where the mount is installed
• Carefully relieve spring tension; note link/cable routing before removal
• Transfer the spring/link to the new mount, secure the bracket, and check door balance on both sides
