Whirlpool WP77001099 Broil Element (3000 W) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Heating Element.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP77001099 replaces AP6011446, 77001099, 0315451, 948309, PS11744642, Y0315451.

Description

This broil element delivers the high, direct heat the oven needs for broiling and finishing foods quickly and evenly. Replace a broken or burned element to restore upper-oven broil performance and consistent browning. What it does:

• Heats the oven's broil zone to provide the direct, high-temperature surface heat used for broiling and browning.
• Replaces a visibly broken, burned, or non-glowing element that prevents the oven from broiling.
• Helps eliminate uneven browning or lack of top-heat when the element fails.
• Works as the OEM-design replacement for compatible Whirlpool oven models when the original broil element no longer functions.

What's included:

• One broil element

Install notes:

• Disconnect power to the appliance at the breaker before beginning any repair.
• Access typically requires removing the oven cavity racks and broil shield or the back panel to detach the element terminals.
• Handle the new element carefully and reconnect terminals securely; avoid forcing the element into place.

This part fixes the following symptoms

• Element will not heat
• Little to no heat when broiling
