Whirlpool WP8053874 Oven Broil Element OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Heating Element.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP8053874 replaces AP6011643, 8053874, 722443, PS11744841.

Description

The oven broil element delivers intense radiant heat from the top of the cavity to sear and brown foods. Replace a burned-out or shorted element to restore reliable broiling performance and even top heat.

• Produces high, radiant heat from above when Broil is selected
• Helps sear meats and brown casseroles quickly and evenly
• Common failure signs: no heat on Broil, weak/uneven browning, visible cracks/blistering or breaks

What's included: 1 broil element Install notes:

• Disconnect power at the breaker and allow the oven to cool completely
• From inside the oven, remove mounting screws, pull the element forward, and disconnect the two wire terminals; support wires so they don't slip back
• Transfer any mounting bracket/spacers from the old element if present; reconnect terminals firmly
• Inspect and replace any heat-damaged terminals; test Broil before final reassembly
