Whirlpool WP8268913 Overfill Control Float (With Retainer) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Dishwasher Valve.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP8268913 replaces AP6012278, 8268913, 906083, PS11745485.

Description

This dishwasher overfill control float mounts in the tub floor and rises with the water level to trip the float switch and stop filling. Replacing a warped or stuck float restores proper fill control and helps prevent leaks. What it does:

• Monitors tub water level and actuates the float switch to shut off the inlet valve
• Helps prevent overfilling and water leaking from the door
• Common symptoms of a faulty float include no fill, continuous filling/overfilling, or inconsistent water level

What's included:

• Float and retainer

Install notes:

• Disconnect power and turn off the water supply before servicing
• Remove the lower rack; lift out the old float
• Access beneath the tub may be required to release/install the retainer
• Ensure the float stem engages the switch lever and moves freely; test-fill and check for leaks
