Whirlpool W11524850 Dispenser Wiring Harness (3-Coil) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11524850 replaces AP7193658.

Description

This 3-coil dispenser wiring harness connects the dispenser controls to the refrigerator's dispenser and ice/water components, restoring reliable electrical signals for proper dispenser operation. It replaces damaged or worn dispenser wiring. What it does:

• Provides three insulated conductors to route power and signals between the dispenser control and dispenser components
• Restores interrupted dispenser function when wires are broken, frayed, or connectors are loose
• Helps eliminate intermittent dispenser operation or non-responsive dispenser buttons
• Prevents short circuits caused by exposed or pinched wiring when installed correctly

What's included:

• One 3-coil dispenser wiring harness with factory-style connectors

Install notes:

• Disconnect power to the appliance before starting any repair
• Access may require removing the dispenser housing or interior panels; keep fasteners organized
• Match connector shapes and pin counts; do not force connectors to mate
• Inspect adjacent wiring and secure the harness away from sharp edges or moving parts
