Whirlpool W11643701 Lower Wire Harness (4.7/4.8-Cu Ft) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Terminal Block, Receptacle.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11643701 replaces AP7205722, W11335100.

Description

This lower wire harness routes power and signals between the control and the components beneath the tub on select 4.7/4.8-cu ft top-load washers. Replacing a damaged harness restores reliable connections and helps resolve intermittent motor or pump operation. What it does:

• Distributes power and control signals to lower-cabinet components
• Supports proper operation of the drive motor, drain pump, and related parts
• Typical symptoms: no spin or agitate, won't drain, intermittent operation, or visible heat damage/corroded connectors
• Match by part number for correct fit on 4.7/4.8-cu ft platform models

What's included:

• 1 lower wire harness assembly

Install notes:

• Disconnect power and water supply before servicing
• Access the underside per your model (tilt the washer or remove panels as required)
• Transfer one connector at a time; route along the factory path and secure with existing clips/ties away from moving parts and sharp edges
• After installation, run a diagnostic or test cycle to normal operation
