Whirlpool W11590868 Lower Wiring Harness (Vmax2.0 Drain Pump) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11590868 replaces AP7186768, W11405459.

Description

This lower wiring harness connects the washer's VMax2.0 control to lower electrical components, routing power and signals to the drain pump and other lower assemblies to help restore reliable pump operation and reduce intermittent electrical faults. What it does:

• Routes power and control signals between the VMax2.0 control system and lower/wet components, including the drain pump.
• Replaces damaged, pinched, or corroded wiring that can prevent the pump or lower assemblies from receiving power.
• Commonly used when the washer won't drain, the pump is unresponsive, or lower electrical components show intermittent faults.
• Matches OEM connector shapes and routing to maintain proper electrical connections and component function.

What's included: One lower wiring harness. Install notes:

• Always disconnect power (unplug or switch off breaker) before accessing internal wiring.
• Inspect connectors and wiring routing for corrosion, bare wires, or chafing; secure harness away from moving parts and sharp edges.
• Match connector orientations during reassembly; ensure all clips and retainers are fastened to prevent strain on terminals.
