Whirlpool W11591637 Lower Wiring Harness (Vmax 2.0 Drain Pump) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Terminal Block, Receptacle.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11591637 replaces AP7186769, W11405458.

Description

This lower wiring harness connects the washer's VMax 2.0 drain pump to the lower control components, restoring reliable electrical connections for proper pump operation and consistent drain cycles. What it does:

• Routes power and signal between the VMax 2.0 drain pump and the washer's lower control assembly.
• Replaces frayed, pinched, or damaged wiring that can cause the pump to run intermittently or not at all.
• Helps resolve symptoms such as no-drain conditions, intermittent pumping, or pump-related error codes.
• Matches original connector ends and routing to fit the factory wiring path.

What's included: One lower wiring harness. Install notes:

• Disconnect power to the appliance before attempting any repairs.
• Access the harness by removing the washer's appropriate access panels per the service manual.
• Follow the original wire routing and fully seat all connectors; avoid pinching or stretching the harness.
