Whirlpool W11501788 Main Wiring Harness (Double-Connector M22) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11501788 replaces AP7208887.

Description

This main wiring harness routes power and signals between controls and major appliance components, restoring electrical connections for proper operation. Replaces a damaged or burned harness to address intermittent power, no-start, or control-function failures. What it does:

• Carries power and control signals between the control board and components
• Restores broken or shorted circuit paths that can cause intermittent operation or no power to subsystems
• Prevents arcing and poor connections that can lead to component failures or unusual behavior
• Matches OEM connector types and routing to ensure correct fit and function

What's included:

• One main wiring harness (double-connector M22), as shown

Install notes:

• Disconnect power before servicing; verify power is off at the breaker
• Compare connector count and routing to the original harness before installation
• Secure harness away from moving parts and heat sources; use existing clips or ties
