Whirlpool W11038118 Control Board Wiring Harness (M22 Hmi, 4.8) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11038118 replaces AP6835591.

Description

This wiring harness connects the control board to the M22 HMI interface, providing the signal and power paths needed for the user interface to operate. It restores reliable connections between the board and control panel. What it does:

• Provides the dedicated wiring and connector(s) between the control board and the M22 human-machine interface (HMI)
• Carries control signals and low-voltage power required for the display and keypad to function
• Common symptom fix: control panel is unresponsive, display blank, or intermittent button response
• Replaces damaged, burned, or loose harness connectors that can cause communication faults

What's included:

• One control board to M22 HMI wiring harness

Install notes:

• Disconnect power to the appliance before starting any repair to avoid shock or damage
• Disconnect and reconnect connectors by the housing—do not pull on wires
• Inspect mating connectors and pins for corrosion or damage before installing the new harness
