Whirlpool W11545744 Lower Wiring Harness (Vmax Dryer) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11545744 replaces AP7018845, W11255099.

Description

This lower wiring harness connects the dryer's lower electrical components so the machine can tumble and heat reliably. It replaces a damaged or worn harness to restore proper electrical connections and safe operation. What it does

• Provides factory-style wiring connections between the control/motor area and lower components (motor, heater/gas valve and sensors)
• Restores power/communication when broken, burned, or corroded wires cause no-start or intermittent operation
• Helps correct symptoms like no tumble, no heat, or intermittent runs when traced to the lower wiring
• Matches OEM routing and connectors to ensure proper fit and electrical contact

What's included

• One lower wiring harness

Install notes

• Disconnect power (and gas supply for gas dryers) before beginning any repair
• Compare the replacement harness to the original to ensure connector types and routing before installation
• Route and secure the harness with existing clips/retainers; avoid pinching or stretching wires
• If you find melted connectors or damage to other components, replace those parts as recommended by the OEM
