Whirlpool 12346502 Main Wiring Harness (Machine Compartment) OEM Part

Manufacturer's Part Number: 12346502
Genuine Whirlpool part
Appliance Compatibility Tool
$20.27

Secure and trusted checkout with

Out Of Stock

Usually ships within 4 - 14 days

Call us 1-877-477-7278
Need Help? Chat with a Pro

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number 12346502 replaces AP4012573, 12346501, 821458, AH2006717, EA2006717, PS2006717.

Description

This wiring harness routes power and signal connections inside the machine compartment to link controls, switches and motors, restoring reliable electrical connectivity for normal operation. What it does:
  • Provides factory-style electrical routing between control boards, switches and motors in the machine compartment
  • Carries power and control signals to enable motor, pump and control functions
  • Failsafe symptom linkage: may be needed when the washer won't start, has intermittent operation, or shows control-related errors
  • Helps replace damaged, frayed or corroded wiring that can cause shorts or unreliable performance
What's included: One machine compartment wiring harness (single harness) Install notes:
  • Disconnect power (unplug or switch off breaker) before accessing internal wiring
  • Access typically requires removing cabinet or service panels—follow your model's service manual
  • Inspect connectors and wire routing; replace only if matching the original harness
