Whirlpool W11132997 Main Wiring Harness (Double-Extended) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11132997 replaces AP6832344, W10571362.

Description

This main wiring harness connects the washer's control and components, restoring reliable electrical pathways for operation and diagnostics. It replaces worn or damaged wiring so the machine can receive power and signal between modules. What it does:

• Transfers power and control signals between the control board and primary components (motors, sensors, valves)
• Replaces frayed, burned, or broken wires that can cause intermittent operation or failure to start
• Helps resolve issues with no power to certain functions or erratic behavior caused by damaged wiring
• Maintains factory routing and connector fit for a secure electrical connection

What's included:

• One main wiring harness (double-extended) as specified

Install notes:

• Disconnect power before starting and follow the washer's wiring diagram for connector locations
• Match connector shapes and colors; route harness away from moving parts and heat sources
• Inspect connectors for damage and secure all fasteners; do not splice unless certified to appliance wiring standards
