Whirlpool W11171472 Main Wiring Harness (Ja Combo Extension) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11171472 replaces AP6783180, W10571361.

Description

This main wiring harness provides the factory-style electrical connection for the JA combo circuits, restoring reliable power and signal routing to the washer's control and motor assemblies. It replaces damaged or frayed wiring to help eliminate intermittent operation. What it does:

• Carries power and control signals between the machine control, motor, and related components
• Replaces burnt, pinched, or corroded wiring that can cause intermittent starts, no-spin, or error codes
• Restores secure connector fit to prevent loose connections and arcing
• Maintains factory routing and strain relief for safe, long-lasting operation

What's included:

• One main wiring harness (JA combo extension) as shown

Install notes:

• Recommended for technicians or experienced DIYers; disconnect power and water before starting
• Inspect connectors and mounting clips during installation; secure harness away from moving parts and heat sources
• Do not splice or patch unless using proper crimp connectors and heat shrink; replace if insulation is damaged
• Run a test cycle to ensure proper operation
