Whirlpool W10834516 Main Wiring Harness (Double) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10834516 replaces AP6802699.

Description

This main wiring harness routes power and signals between a washer's control board and major components, restoring reliable electrical connections for operation and control. Ideal when wiring is damaged, burnt, or intermittent. What it does:

• Connects the control board to motors, valves, sensors, and switches so the washer can run cycles.
• Replaces frayed, broken, or burned wiring that causes intermittent power or function loss.
• Helps resolve symptoms like failure to start, no spin, or inconsistent cycle behavior linked to wiring faults.
• Maintains factory-style connector fit and wire routing for proper component connections.

What's included:

• 1 main wiring harness

Install notes:

• Disconnect power before servicing to avoid electrical shock.
• Inspect connectors and mating terminals for corrosion; replace if damaged.
• Route and secure harness to avoid contact with moving parts or hot surfaces.
